7.4V 2000mAh 18650 Massager Lithium-ion Battery
HG2AE4301
7.4V 2000mAh 18650 Massager Lithium-ion Battery
Model: HG2AE4301
Voltage: 7.4V
Capacity: 2000mAh
Structure: 2S1P
Application field: personal health care, electronic products
Model: HG2AE4301
Voltage: 7.4V
Capacity: 2000mAh
Structure: 2S1P
Application field: personal health care, electronic products
Quantity
Lithium-ion Battery Specification
| Description: | 7.4V 2000mAh 18650 Massager Lithium-ion Battery |
| Product No.: | HG2AE4301 |
| Cell model: | 18650 / 2000mAh / 3.7V |
| Battery Specification: | 2S1P / 2000mAh / 7.4V |
| Nominal voltage: | 7.4V |
| Nominal capacity: | 2000mAh |
| Charging voltage: | 8.4V |
| Charging current: | 1000mA |
| Discharge current: | 1000mA |
| Maximum discharge current: | 2000mA |
| Discharge cut-off voltage: | 5.5V |
| Internal resistance : | ≤240mΩ |
| Delivery voltage: | 7.2-8.4V |
| Battery weight: | 100g |
| Product size: | 136 * 23.5mm (Max) |
| Operating temperature: | Charging temperature: 0-45°C; Discharge temperature: -20-60°C |
| Storage temperature environment: | 1month - 20-60 ° C; 3months - 20-45 ° C; 12months - 20-25 ° C |
| Relative humidity: | 65 ± 20% |
| Battery structure: | |
| Lithium Battery protection: | short circuit protection, overcharge protection, overdischarge protection, overcurrent protection, etc. |
| Application field: | Massager, personal health care, electronic products powered by Lithium-ion Battery |
